容量選擇                     Capacity(optional)

10,   20, 50, 100, 200, 500kg

單位切換                     Unit(Switchable)

Kg,   N,kN

荷重解析度                 Load   Resolution

1/10000

力量放大倍率               Load   Magnifying Rate

全程不分檔Full, regardless of the file

行程（不含夾具）       Stroke(exclude the   grips)

980mm

有效寬度                   Effective   width

360mm

測試速度                   Test   speed

0.1~   500mm/min

位移分解度                 Stroke   Resolution

0.01mm

馬達                       Motor

步進伺服馬達inverter motor

驅動器                     Drive

伺服驅動器AC Drive

螺桿                       Screw

滾珠螺桿Ball screw

體積                       Dimension(WxDxH)

660×545×1610mm

重量                         Weight(approx..)

160kg
