容量選擇                       Capacity(optional)

2000,3000,5000kg

單位切換                       Unit(Switchable)

Kg, lb, N,kN

荷重解析度                   Load   Resolution

1/50000

行程（不含夾具）      Stroke (exclude   the   grips)

1000mm

有效寬度                      Effective   width

420mm

測試速度                      Test   speed

0.1~500mm/min

位移分解度                   Stroke   Resolution

0.01mm

馬達                             Motor

AC JMC伺服馬達inverter Motor

驅動器                         Drive

JMC伺服驅動器VC Drive

減速機                         Reducer

行星減速機Precision planetary reducer

螺桿                            Screw

滾珠螺桿Ball screw

體積                           Dimension(WxDxH)

920×430×1850mm

重量                          Weight(approx..)

260kg
